Start with the layout, not the fixtures
The cheapest kitchen plumbing is the plumbing that stays where it is. Supply lines and the drain come out of the wall at fixed spots, and moving the sink means moving both. Before you pick a new island sink or a farmhouse basin, find out where the existing drain and vent are.
If you want the sink in a new spot, tell your plumber early. A sink on an island needs a vent that does not exist in a normal wall, and there are approved ways to build one. A drain that has to cross a floor needs enough slope to work, which affects cabinet height and flooring.
What goes where
| Fixture | Supply | Drain | Notes |
|---|---|---|---|
| Sink | Hot and cold with stop valves | Trap, tailpiece, tie-in to the drain and vent | Single or double bowl changes the drain layout |
| Dishwasher | Hot supply through a dedicated stop | Drain hose to the disposal or a tailpiece, with a high loop or air gap | Needs a proper loop so wastewater cannot siphon back |
| Garbage disposal | None | Mounts under the sink drain, outlet to the trap | Needs power and a switch or plug |
| Refrigerator ice maker | Cold line with a stop | None | Use proper tubing and keep slack for pulling the fridge |
| Pot filler or gas range | Pot filler: cold line. Range: gas line | None | Gas needs a pressure test and a permit type of its own |
Supply stops: the small valves that save big messes
Every fixture should have its own shutoff under the sink or behind the unit. That way a leaking faucet or a failed supply line can be isolated without shutting off the house. During a remodel, replace old stops. Corroded valves that have not been turned in years often leak or stick the day you need them.
Use braided or solid supply lines sized for the faucet, and make sure the hose is not kinked behind the cabinet. If a stop valve will not turn, do not force it. A broken valve can turn a quiet job into a flood.
Dishwasher: loop it or gap it
A dishwasher drains dirty water, and that water must not be able to flow back into the machine. Most installs handle that with a high loop in the drain hose, secured under the countertop, or with an air gap. Skipping the loop is one of the most common remodel errors.
The drain hose usually ties into the disposal inlet or a side tailpiece on the sink drain. If you have a disposal, the knockout plug inside the inlet has to be removed before the hose will drain, and forgetting it makes the dishwasher back up into the sink.
Garbage disposal: installation and limits
A disposal bolts under the sink flange and connects to the trap. It needs a nearby outlet and a switch. The unit grinds soft food scraps, but it does not cope well with grease, fibrous peels and bones.
Grease
It cools and sticks to pipe walls. Wipe pans before washing and put grease in the trash.
Fibrous food
Celery, corn husks and onion skins wrap around the blades and clog the trap.
Starches
Rice, pasta and potato peels swell and form a paste that blocks the drain.
Hard items
Bones, fruit pits and shells can jam the unit or damage it.
If an existing unit hums, leaks from the bottom or will not turn, garbage disposal repair can tell you whether a reset, a seal or a replacement is the answer.
Water, grease and kitchen plumbing in Jacksonville Beach
The City of Jacksonville Beach provides water and sewer itself. Its water comes from six wells in the Floridan Aquifer and is aerated to remove hydrogen sulfide, the rotten-egg smell, and then chlorinated. The city report does not state hardness, so if you want to know how your water treats a new faucet or dishwasher, test your tap or ask the Water Division at 904-247-6241.
The city also runs a Grease Interceptor program under Ordinances 2019-8125 and 2020-8156, aimed at restaurants and similar businesses. It is not a home rule, but it shows why the city cares about grease in the sewer system. Keep it out of your kitchen drain at home too.
Permit awareness for a kitchen remodel
The city's plumbing e-permit asks you to classify the job as alteration, new, re-pipe, repair, fuel gas or other. A kitchen remodel that moves a sink or adds a gas line typically fits alteration or fuel gas, and the type of work could be DWV on private property or gas piping only. The city says work may not begin until a permit is approved and posted.
We do not tell homeowners which small jobs are exempt, because the answer depends on the work. Ask the Building Inspection Division at 904-247-6100 about your project. For jobs we install, we pull the permit and schedule the inspection.
What a remodel plumber does, step by step
The usual order
- Shut off water and disconnect old fixtures, check stops and supply lines
- Open the wall or floor if drains or vents need to move, and rough in new lines
- Pressure test supply lines and fill the drain to check for leaks
- Wait for inspection where a permit applies, then close the walls
- Set the sink, faucet, disposal and dishwasher connections after cabinets and counters
- Run every fixture, check under the cabinet and test the shutoffs
If the remodel exposes old supply pipe in poor shape, ask about repiping while the walls are open. It is the cheapest time to do it. For the rest of the work, our plumbing installation team handles the layout, the permit and the install together.
What to do yourself and when to call
| Task | Reasonable to try | Call a plumber |
|---|---|---|
| Swap a faucet | Yes, if the stops work and the supply lines are in good shape | Stops leak or the mounting is corroded |
| Replace a trap | Yes, with proper fit and no strain on the drain | The drain wall pipe is damaged |
| Move a sink | No | Always, since drain and vent change |
| Add a gas range | No | Always, since gas lines need a pressure test |
| Hook up a dishwasher | Possible, with a loop | Hose will not drain or the knockout is in doubt |
If you are working on a home in a neighboring town, our crew from the Neptune Beach service area covers the same work.
Kitchen sink traps, vents and dishwasher connections are laid out under the IPC based Florida Building Code, Plumbing. That is why an inspector checks the rough-in before drywall closes the wall.
Quick answers for Jacksonville Beach homeowners
It depends on the work. The city's plumbing e-permit asks you to classify it, and the Building Inspection Division decides what applies. Ask them at 904-247-6100 before you start.
That usually means the disposal knockout plug was never removed, or the drain hose is blocked or lacks a proper loop. A plumber can check the hose and the inlet quickly.
Most sinks have a standard drain opening that fits one, but you need power nearby. Some septic homes should avoid heavy disposal use, so ask about your system.
Each fixture should have its own: two for the faucet, one for the dishwasher and one for the ice maker. A main shutoff for the house is also essential.
Check the drain first. Food buildup and a dry trap cause most kitchen smells. Hydrogen sulfide in water is another cause, and the city aerates its water to remove it. If hot water only smells, the water heater may be involved.
If your remodel plan includes moving a sink or adding a gas line, call before the cabinets are ordered.
